Unlocking Design Freedom & Cost Efficiency
3D printing stainless steel (316L/17-4PH) dissolves traditional manufacturing barriers, enabling complex geometries impossible with CNC or casting. By eliminating tooling costs and slashing lead times by 85%, stainless steel 3D printing provides unprecedented agility for mission-critical applications. Our DMLS/SLM technology achieves 99.98% density with surface roughness down to Ra 1.6μm – outperforming sand casting by 400% in precision while cutting costs by 30-60%.
4 Strategic Cost Advantages
1. Zero Tooling Investment
- Save 8k−50k on molds/dies for prototypes & batches <500 units
- Design modifications at 90% lower cost (Case: Chemical reactor nozzle redesign: 220vs.2,100 CNC)
2. Material & Time Savings
| Process | Lead Time (Complex Part) | Material Waste |
|---|---|---|
| CNC Machining | 3-6 weeks | 70% |
| Our 3D Printing | 72 hours | <5% |
3. Integrated Post-Processing
- 🌟 Low-cost marine impellers: Salt-spray tested 316L parts at **95/unit∗∗(vs.280 cast)
- HIP + Bead blasting bundle: **55/part∗∗(Externalavg:175)
4. Volume-Based Pricing
markdown
复制
| Qty | Price/kg 316L | Lead Time |
|---------|---------------|------------|
| 1-10 | $195 | 3 days |
| 11-50 | $167 | 5 days |
| 50+ | $142 | 8 days | Industry Applications & ROI
1. Marine & Chemical Processing
- 🌟 Corrosion-resistant reactor grids:
- 316L printed units: **1,850∗∗(vs.4,200 welded assembly)
- 25-year saltwater corrosion warranty
- 🌟 Food-safe stainless housings:
- Ra 0.8μm electropolished surfaces
- FDA-compliant, CIP/SIP sterilizable
2. Energy & Automotive
- 17-4PH hydraulic manifolds:
- H900 heat-treated: 1,300 MPa tensile strength
- 55% weight reduction → 31% efficiency gain
- Turbine combustion liners:
- Thermal fatigue life extended 3x vs. casting
3. Tooling & Industrial Equipment
- Conformal cooling molds:
- Cycle time reduction: 22 seconds → 14 seconds
- ROI in <8 weeks (Medical device case study)
- 🌟 High-strength tooling inserts:
- 17-4PH at 45 HRC: Wear resistance +200% vs. tool steel
Technical Edge & Certifications
Advanced Manufacturing
- SLM Solutions SLM 500 (4 × 700W lasers)
- Build Volume: 500 × 280 × 365 mm
- Tolerances: ±0.1mm + 0.1mm/mm
Quality Assurance
- Material Certs: ASTM A276, AMS 5634
- Process Certs: ISO 9001:2015, NADCAP
- Testing: ASTM E8 tensile, ASTM G48 corrosion
Workflow: From Design to Delivery
Limited Offer (Valid until 2025-07-31):
- Upload 3D Model → AI-driven DFM analysis (Free)
- Material Selection:
- 316L (Corrosion focus) / 17-4PH (Strength focus)
- Choose Delivery:
- ✳️ 5-Day Express: Free expedited shipping
- 📊 Certification Package: +$85 (CT scans + material certs)
